Home > Product > SFP Optical Transceiver > 1.25G SFP BIDI TX1490/RX1310NM 40KM
1.25G SFP BIDI TX1490/RX1310NM 40KM
1.25G SFP BIDI TX1490/RX1310NM 40KM
  • 1.25G SFP BIDI TX1490/RX1310NM 40KM
  • Item : SLB-1243X-40-X
  • NameValue
    PackageBIDI SFP
    Data Rate(G)1.25
    WavelengthTx1490/Rx1310
    ConnectorSimplex LC/SC
    Reach40Km
    Temp0-70
    DDMYES/NO
    Fiber TypeSMF
  • The SFP-BIDI transceivers are high performance, cost effective modules supporting dual data-rate of 1.25Gbps/1.0625Gbps and 40km transmission distance with SMF.

    The transceiver consists of three sections: a DFB laser transmitter, a PIN photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements.

    The transceivers are compatible with SFP Multi-Source Agreement (MSA) and SFF-8472. For further information, please refer to SFP MSA.

Features
Parameter
Application
  • Dual data-rate of 1.25Gbps/1.063Gbps operation
  • 1490nm DFB laser and PIN photodetector for 40km transmission
  • Compliant with SFP MSA and SFF-8472 with simplex LC or SC receptacle
  • Digital Diagnostic Monitoring:
  • Internal Calibration or External Calibration
  • Compatible with SONET OC-24-LR-1
  • Compatible with RoHS
  • +3.3V single power supply
  • Operating case temperature range of
  • 0°C to +70°C (Commercial) or -40°C to +85°C (Industrial)
Package (Form Factor) BIDI SFP
Data Rate (typical) 1.25 Gb/s
Centre Wavelength Tx1490nm/Rx1310nm
Distance 40km
Diagnostics Digital Monitor
Transmitter DFB Laser
Receiver PIN photo detector
TX Output Power (dBm) -5~0
RX Sensitivity (dBm) -23
Low/High Case Temperature  0°C~70°C
Voltage Supply (typical) 3.3v
Connector Simplex LC/UPC
  • Gigabit Ethernet
  • Fiber Channel
  • Switch to Switch interface
  • Switched backplane applications
  • Router/Server interface
  • Other optical transmission systems
