Home > Product > SFP Optical Transceiver > 155M SFP 1310NM 40KM
155M SFP 1310NM 40KM
155M SFP 1310NM 40KM
  • 155M SFP 1310NM 40KM
  • Item : SLS-1531-40-X
  • NameValue
    PackageSFP
    Data Rate(G)155M
    Wavelength1310nm
    ConnectorDuplex LC
    Reach40km
    Temp0-70
    DDMYES/NO
    Fiber TypeSMF
  • The SFP transceivers are high performance, cost effective modules supporting 155Mbps data-rate and 40km transmission distance with MMF.

    The transceiver consists of three sections: a FP laser transmitter, a PIN photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class 1 laser safety requirements.

    The transceivers are compatible with SFP Multi-Source Agreement (MSA) and SFF-8472. For further information, please refer to SFP MSA.

Features
Parameter
Application
  • Up to 155Mbps data-rate
  • 1310nm FP laser and PIN photo detector for 40km transmission
  • Compliant with SFP MSA and SFF-8472 with duplex LC receptacle
  • Digital Diagnostic Monitoring
  • Internal Calibration or External Calibration
  • Compatible with RoHS
  • +3.3V single power supply
  • Operating case temperature:
  • Standard : 0 to +70°C
  • Industrial : -40 to +85°C
Package (Form Factor) SFP
Data Rate (typical) 155 Mb/s
Centre Wavelength 1310nm
Distance 40km
Diagnostics Digital Monitor
Transmitter Fabry-Perot Laser
Receiver PIN photo detector
TX Output Power (dBm) -5~0
RX Sensitivity (dBm) -34
Low/High Case Temperature  0°C~70°C
Voltage Supply (typical) 3.3v
Connector Duplex LC/UPC
  • SDH STM-1, S-1.1,L-1.1, L-1.2
  • SONET OC-3 IR1,LR1,LR2
  • Other optical links
