| Name | Value |
| Product Description | QSFP28 DWDM |
| Data Rate | 100Gbit/s |
| Reach | 80km |
| Tx | Cooled EML DWDM |
| Rx | PIN-PD |
| Connector | Dual CS SM |
Sourcelight QSFP28 100G DWDM PAM4 is a pluggable, DWDM, fiber-optic transceiver for 100 Gigabit Ethernet (100GbE) applications. This module is designed for data center interconnect, which requires high fiber-capacity for links up to 80 km.
| Package (Form Factor) | QSFP28 ZR4+ |
| Data Rate (typical) | 25.78 Gbps/CH |
| Centre Wavelength | CH17~CH60+ |
| Distance | 80km |
| Diagnostics | Digital Monitor |
| Transmitter | Cooled EML DWDM |
| Receiver | PIN-PD |
| TX Output Power (dBm) | -1~+7dBm |
| RX Sensitivity (dBm) | -7.2dBm |
| Low/High Case Temperature | 0°C~70°C |
| Voltage Supply (typical) | 3.3v |
| Connector | Dual CS |
