Sourcelight SFP+ LRM is an optical transceiver module for transmission at 1310nm over legacy multimode fiber. Supporting 10GBASE-LRM Ethernet standard make it ideally suited for 10G datacom. Its very low power consumption and its excellent EMI performance allow system design with high port density. The small form factor integrates a 1310nm Fabry-Perot (FP) laser in an LC package and a linear multimode PIN receiver.
Sourcelight SFP+ LRM transceiver is a linear-interface transceiver that enables, in conjunction with an Electronic Dispersion Compensation (EDC) on the host board, an IEEE802.3aq 10GBASE-LRM compliant link. The host board EDC provides correction for the severe modal dispersion that may occur during propagation through multimode fiber links, including legacy installed FDDI multimode fiber (see IEEE802.3aq for detailed information regarding fiber coverage).
|Package (Form Factor)||SFP+|
|Data Rate (typical)||10.3 Gb/s|
|Distance||220m For MMF|
|Receiver||PIN photo detector|
|TX Output Power (dBm)||-6.5~-0.5|
|RX Sensitivity (dBm)||-6.5|
|Low/High Case Temperature||0°C~70°C|
|Voltage Supply (typical)||3.3v|
