10G XFP 1310NM 10KM DDM

10G XFP 1310NM 10KM DDM
Item : SLXF-1031-LR
Name Value

Package XFP LR
Data Rate 10Gbit/s
Wavelength 1310nm
Connector Duplex LC
Reach 10km
Temp 0-70
DDM YES
Fiber Type SMF
Sourcelight XFP LR is compliant with the 10G Small Form-Factor Pluggable (XFP) Multi-Source Agreement (MSA), supporting data-rate of 10.3125Gbps(10GBASE-LR) or 9.953Gbps 10GBASE-LW), and transmission distance up to 10km on SMF.

The transceiver module comprises a transmitter with 1310nm Uncooled DFB laser and a receiver with a PIN photodiode. Transmitter and receiver are separate within a wide temperature range of 0℃ to +70℃ and offers optimum heat dissipation and excellent electromagnetic shielding thus enabling high port densities for 10G systems.

Supports 9.95Gb/s to 11.1Gb/s bit rates
Hot-pluggable XFP footprint
Maximum link length of 10km with SMF
1310nm uncooled DFB laser
XFP MSA package with duplex LC connector
No reference clock required
+1.8V,+3.3V Supply Voltage
XFI and lineside loopback Mode Supported
-5ºC to 70ºC Operating Case Temperature
Diagnostic Performance Monitoring of module temperature, Supply Voltages, laser bias current, transmit optical power, and receive optical power
RoHS6 compliant (lead free)
